Studio Electronics SE88 Filter

All Controls and Patch Points

• FREQUENCY MODE 1 – Adjusts the frequency, or cutoff of Mode 1.
• 2/3 - 1/3 TRACK - Toggles tracking options for Mode 1.
• FM IN - Adjusts the master frequency modulation input.
• FULL - HALF TRACK - Toggles tracking options for Mode 2.
• FREQUENCY MODE 2 - Adjusts the frequency, or cutoff of Mode 2.
• RESONANCE – Adjusts the resonance of Mode 1's filter.
• M1 FM - Adjusts Mode 1's frequency modulation.
• RESONANCE – Adjusts the resonance of the Mode 2's filter.
• HP / BR - Toggles the High-Pass and Band-Reject option.
• M1 RES CV – Adjusts Mode 1's resonance control voltage.
• M2 RES CV – Adjusts Mode 2's resonance control voltage.
• INPUT – Adjusts the master audio input.
• M2 FM – Adjusts Mode 2's frequency modulation.
• OUTPUT – Adjust the audio output.
• 1 V/O – One volt per octave control voltage input.
• FM IN – Master frequency modulation input.
• M1 FM – Mode 1 frequency modulation input.
• M2 FM – Mode 2 frequency modulation input.
• M1 RES CV – Mode 1 resonance control voltage input.
• M2 RES CV – Mode 2 resonance control voltage input.
• M1 IN – Mode 1 input.
• LEVEL – Level control for Mode 1.
• M1 OUT – Mode 1 output.
• M2 IN – Mode 2 input.
• LEVEL – Level control for Mode 2.
• M2 OUT – Mode 2 output.

Vitals

• Size - 20hp
• Depth - 39.7mm with ribbon cable attached
• Power Usage - 42mA (+12 / -12)
